METRO 120 ERV-ECM-FID
CSA HVI ISO sticker HRAI Member

SPECIFICATIONS

MODEL:METRO 120 ERV-ECMVOLTAGE:120 VFREQUENCY:60 HzPHASE:N/ACURRENT:1.4 AAIRFLOW HIGH:117 CFMWEIGHT:34 lbDRAIN:NoWARRANTY:

Units carry a 5 year warranty on the ERV core and a 5 year replacement parts warranty

LIFEBREATH

METRO 120 ERV-ECM

Energy Recovery Ventilator

  • 117 CFM @ .3″ w.g / 72% (SRE) at 49 CFM and 0°C (32°F)
  • Designed for high-rise condos, apartments and townhomes with limited mechanical space
  • High efficiency ECM motors
  • Low profile, fits in bulkhead and drop ceilings, slim height 9.75”
  • Flexible CFM operational range
  • Brackets included for easy installation
  • No drains required
  • Removable motor and electronic assembly for easy maintenance and service
  • Convenient hinged door – no screws
  • Hardwired, Auto Balance, and Fault Indicator Display configurations available
  • Title 24 Compliant. A FID enabled ERV is capable of displaying error codes for certain types of faults which impact operation of the system. FID Version Only
CSA HVI ISO sticker HRAI Member

SPECIFICATIONS

MODEL:METRO 120 ERV-ECMVOLTAGE:120 VFREQUENCY:60 HzPHASE:N/ACURRENT:1.4 AAIRFLOW HIGH:117 CFMWEIGHT:34 lbDRAIN:NoWARRANTY:

Units carry a 5 year warranty on the ERV core and a 5 year replacement parts warranty
